LED panel, building-in, round 12W, 4000K, 220-240V AC

Aрт. № PR1240
LED panel, building-in, round 12W, 4000K, 220-240V AC
LED panel, building-in, round 12W, 4000K, 220-240V AC LED panel, building-in, round 12W, 4000K, 220-240V AC

LED panel, building-in, round 12W, 4000K, 220-240V AC

Art № PR1240
Energy class F
description:

LED panel, building-in, round, 12W, 4000K (neutral light) Ultralux with the following advantages:

  • The construction type helps achieve high energy efficiency – 105 lm/W.
  • The PCB has an integrated non-dimmable driver, guaranteeing long exploitation period.
  • Quick and easy mounting through building-in or by frame for surface mounting.
  • Housing made of ABS plastic and polycarbonate diffuser, ensuring better mechanical strength and heat dissipation.
  • Wide beam angle – 120°, suitable for general lighting.

The line of LED panels for building-in, consisting of totally 11 round and square shaped models. Four of them are offered in neutral colour temperature (4000K) and respectively, 5W power – PR540, 12W – PR1240, 18W – PR1840 and 24W – PR2440. The PRW5CCT, PR12CCT, PR18CCT models are with round shape and respectively, 5W power – PRW5CCT, 12WPR12CCT, 18W – PR18CCT, and option for choice of colour temperature (3000/4000/6500K). The PRW5CCT panel has a higher ingress protection rate (IP54). The square models are offered in 4000K and with 5W power – PS540, 12W – PS1240, 18W – PS1840, 24W – PS2440

specifications:
Power 12W
Voltage AC 220-240V
Frequency 50-60Hz
Driver built-in, non-dimmable
Dimmable no
Protection rating IP20
Working temperature range -10 °C ÷ +40 °C
On/Off cycles >12000
Dimensions 145/30mm
Mounting hole 120mm
Lumen Maintenance LM80 >20000h
Starting time <0.2sec
Warranty 2 years
Rated luminous flux 1200lm
Flicker Flicker-free
Correlated Color Temperature (CCT) 4000K
Color Rendering Index (CRI) ≥80
Beam angle 120⁰
LED type SMD2835
description:

LED panel, building-in, round, 12W, 4000K (neutral light) Ultralux with the following advantages:

  • The construction type helps achieve high energy efficiency – 105 lm/W.
  • The PCB has an integrated non-dimmable driver, guaranteeing long exploitation period.
  • Quick and easy mounting through building-in or by frame for surface mounting.
  • Housing made of ABS plastic and polycarbonate diffuser, ensuring better mechanical strength and heat dissipation.
  • Wide beam angle – 120°, suitable for general lighting.

The line of LED panels for building-in, consisting of totally 11 round and square shaped models. Four of them are offered in neutral colour temperature (4000K) and respectively, 5W power – PR540, 12W – PR1240, 18W – PR1840 and 24W – PR2440. The PRW5CCT, PR12CCT, PR18CCT models are with round shape and respectively, 5W power – PRW5CCT, 12WPR12CCT, 18W – PR18CCT, and option for choice of colour temperature (3000/4000/6500K). The PRW5CCT panel has a higher ingress protection rate (IP54). The square models are offered in 4000K and with 5W power – PS540, 12W – PS1240, 18W – PS1840, 24W – PS2440
