LED high bay with dimmable driver 0-10V, 200W, 5000K, 100-277V AC, IP65

Aрт. № LIKX20050
LED high bay with dimmable driver 0-10V, 200W, 5000K, 100-277V AC, IP65
LED high bay with dimmable driver 0-10V, 200W, 5000K, 100-277V AC, IP65 LED high bay with dimmable driver 0-10V, 200W, 5000K, 100-277V AC, IP65 LED high bay with dimmable driver 0-10V, 200W, 5000K, 100-277V AC, IP65 LED high bay with dimmable driver 0-10V, 200W, 5000K, 100-277V AC, IP65

LED high bay with dimmable driver 0-10V, 200W, 5000K, 100-277V AC, IP65

Art № LIKX20050
description:

A new model LED industrial lamp (highbay) with 200W power, innovative construction, excellent efficiency, compact size, and lighter weight. It is offered in neutral 5000K light with the following advantages:

  • Innovative construction with central heat dissipation cavity, ensuring better cooling and longer diode life;
  • Very high efficiency > 150 lm/W;
  • High quality LED chips Osram Duris;
  • The emitted light is flicker free;
  • The customer can choose from 60° and 90°,  polycarbonate diffusers with UV-protection (sold separately);
  • Dimmable driver ZH POWER – a sure guarantee for reliable operation and long exploitation period. ZH is an established high-tech brand with proven quality;
  • Controlling signal is 0-10V DC and allows dimming from 0% to 100%;
  • Built-in overvoltage protection 4 kV;
  • Powder-coated aluminum housing that ensures mechanical strength and excellent diode cooling;
  • A ring and a bracket (included in the set) allow a choice of mounting;
  • Compact size and lighter weight;
  • High ingress protection rate  -  IP65;
  • High impact resistance rate IK08.
  • Long warranty – 5 years;

Application:

  • Lighting of working areas;
  • Lighting of factories;
  • Lighting of warehouses;
  • Industrial lighting;
  • Interior and exterior lighting
specifications:
Power 200W
Voltage AC 100-277V
Frequency 50-60Hz
Power factor >0.95
Driver With built-in 4 kV surge protection according to IEC 61000-4-5
Dimmable yes
Protection rating IP65
Impact protection rate IK08
Working temperature range -20 ⁰C ÷ +50 ⁰C
On/Off cycles >30000
Lumen Maintenance LM80 >50000h
Height 225mm
Diameter 320mm
Warranty 5 years
Rated luminous flux 30000lm
Efficiency 150lm/W
Correlated Color Temperature (CCT) 5000K
Color Rendering Index (CRI) ≥80 (85 optional)
LED type OSRAM Duris
description:

A new model LED industrial lamp (highbay) with 200W power, innovative construction, excellent efficiency, compact size, and lighter weight. It is offered in neutral 5000K light with the following advantages:

  • Innovative construction with central heat dissipation cavity, ensuring better cooling and longer diode life;
  • Very high efficiency > 150 lm/W;
  • High quality LED chips Osram Duris;
  • The emitted light is flicker free;
  • The customer can choose from 60° and 90°,  polycarbonate diffusers with UV-protection (sold separately);
  • Dimmable driver ZH POWER – a sure guarantee for reliable operation and long exploitation period. ZH is an established high-tech brand with proven quality;
  • Controlling signal is 0-10V DC and allows dimming from 0% to 100%;
  • Built-in overvoltage protection 4 kV;
  • Powder-coated aluminum housing that ensures mechanical strength and excellent diode cooling;
  • A ring and a bracket (included in the set) allow a choice of mounting;
  • Compact size and lighter weight;
  • High ingress protection rate  -  IP65;
  • High impact resistance rate IK08.
  • Long warranty – 5 years;

Application:

  • Lighting of working areas;
  • Lighting of factories;
  • Lighting of warehouses;
  • Industrial lighting;
  • Interior and exterior lighting
