Power supply 5V DC, 100W, IP20

Aрт. № ZNWJ5100
Power supply 5V DC, 100W, IP20

Power supply 5V DC, 100W, IP20

Art № ZNWJ5100
description:

UltraLux LED strip power supplies convert standard AC voltage (230V AC) into a constantly stabilized output voltage of 5V, 12V, 24V, 48V DC (depending on the model). They are manufactured using the latest technologies with quality electronic components. They have compact size, high efficiency (over 90%), low heat loss (no cooling fan), built-in protection against overload, overheat and short-circuit, do not emit electromagnetic interference.

Model ZNWJ5100 has the following features:

  • output voltage in a narrow range +/- 15%;
  • adjustable supply voltage: 90-130V AC / 180-260 V AC.
specifications:
Input voltage AC 90-130 / 180-260V
Frequency 50-60Hz
Maximum power 100W
Output voltage 5V
Class I
Maximum current 5A
Protection rating IP20
Working temperature range -10 °C ÷ +40 °C
Dimensions 198/98/42mm
Warranty 2 years
description:

UltraLux LED strip power supplies convert standard AC voltage (230V AC) into a constantly stabilized output voltage of 5V, 12V, 24V, 48V DC (depending on the model). They are manufactured using the latest technologies with quality electronic components. They have compact size, high efficiency (over 90%), low heat loss (no cooling fan), built-in protection against overload, overheat and short-circuit, do not emit electromagnetic interference.

Model ZNWJ5100 has the following features:

  • output voltage in a narrow range +/- 15%;
  • adjustable supply voltage: 90-130V AC / 180-260 V AC.
